Driving Recorder 1s

Main Features:  3 inch screen and F1.8 aperture  140 degrees wide angle and 1920 x 1080P resolution  Adopting MSC8328P chip, IMX307 CMOS image sensor and Mstar 1080P image process chip  WiFi connection reaches real-time transmission, no need to consume flows of SIM card  Loop-cycle recording, saves the storage space efficiently  Gravity sensor keeps the video not covered in case of an emergency  Auto power on, no need to operate it by your hands  Parking monitoring brings security for your car  Advanced H.264 photography compression technology keeps high quality videos and plays a part of saving storage as well  Support maximum 64GB TF card memory storage ( not included )

Specification

General

Brand: Xiao mi  Model: 1S  Chipset: MSC8328P  Image Sensor: CMOS  Features: HD  Function: G-sensor,HDMI output,Night Vision,Parking Monitoring

Storage

Max External Card Supported: TF 64G (not included)  Class Rating Requirements: Class 10 or Above

Display

Screen type: IPS

Power

Battery Type: Built-in  Battery Capacity (mAh): 470mAh Li-ion Battery  Working Time: 1 day  Working Voltage: DC 5V

Primary Info.

Lens Size: F1.8  Screen size: 3.0inch

Video/Image/Audio

Video Resolution: 1080P (1920 x 1080)  Video System: NTSC  Video Frame Rate: 30fps  Video Output: AV-Out,HDMI  Audio System: Built-in microphone/speacker (AAC)

Functions

WIFI: Yes  WiFi Function: Image Transmission,Remote Control,Settings,Sync and Sharing Albums  WiFi Network Frequency: 2.4GHz  WiFi Dis tance : 6m  Waterproof: No  Waterproof Rating : 0  Loop-cycle Recording : Yes  Loop-cycle Recording Time: 20min  Motion Detection: No  Motion Detection Dis tance: 0  Night vision : Yes  Night Vision Dis tance: 20m  GPS: No  Anti-shake: No  Parking Monitoring: Yes

Other

Operating Temp.: -10 - 60 Deg.C  Power Cable Length: 3.5m

Dimension/Weight

Product weight: 0.0800 kg  Package weight: 0.4000 kg  Product size (L x W x H): 8.80 x 5.30 x 2.80 cm / 3.46 x 2.09 x 1.1 inches  Package size (L x W x H): 20.00 x 10.00 x 10.00 cm / 7.87 x 3.94 x 3.94 inches

Package Contents

Package Contents: 1 x Car DVR, 1 x Car Charger, 1 x Power Cable, 2 x Sticker, 1 x Stick, 1 x Stand, 1 x English User Manual
